Tapered roller bearing 8085 HA4 NTE 630 × 850 × 426 mm
Specifications
8085 HA4 NTE
- Designation
- 8085 HA4
- Manufacturer
- NTE
- Inner diameter d
- 630 mm
- Outer diameter D
- 850 mm
- Height T
- 426 mm
- Width B
- 200 mm
- Dynamic load rating C
- 7524 kN
- Static load rating C0
- 22 754 kN
- Weight
- 690 kg
- Outer ring width C
- 424 mm
- Rolling elements
- Tapered roller
- Load type
- Radial and axial
- Number of rows
- Multilayered
Product summary
8085 HA4: tapered roller bearing, brand NTE. Bore diameter d 630 mm, outside diameter D 850 mm, mounting height T 426 mm. Dynamic load rating C 7524 kN, static load rating C0 22 754 kN, weight 690 kg.
Tapered raceways and rollers whose cone apexes meet on the bearing axis. Carries combined loads: radial and axial in one direction. Can be mounted in pairs, with the clearance or preload set during mounting. Suitable for heavy and shock loads.
779/630 HM
Where it is used
Wheel hubs, shafts of bevel-helical and worm gearboxes, machine tool spindles, drums and rollers. Mounted in pairs in an O or X arrangement, with the axial clearance or preload adjusted during mounting.
When not to use
Do not fit it instead of a ball or cylindrical roller bearing: without a second support that closes the axial force, a tapered roller bearing has no preload. The rollers unload and start sliding on the raceway instead of rolling, which leads to scoring and rapid failure. Note that matching d and D proves nothing: a tapered roller bearing is specified by its mounting height T instead of the width B, so the seat width differs and the assembly needs adjustment during mounting.
Technical data is for information only. Drawings may not show all design features.
