Toroidal roller bearing C 2218 K/C3 SKF 85 × 160 × 40 mm
Specifications
C 2218 K/C3 SKF
- Designation
- C 2218 K/C3
- Manufacturer
- SKF
- Inner diameter d
- 85 mm
- Outer diameter D
- 160 mm
- Width B
- 40 mm
- Weight
- 3.75 kg
- Radial clearance
- C3
- Rolling elements
- Toroidal roller bearings
- Load type
- Radial
- Permissible axial displacement s
- 9.5 mm
Product summary
C 2218 K/C3: toroidal roller bearing, brand SKF. Bore diameter d 85 mm, outside diameter D 160 mm, width B 40 mm. Weight 3.75 kg.
Long, slightly crowned rollers on toroidal raceways: compensates for both misalignment and axial displacement of the shaft within the bearing, without passing additional load to the support.
Where it is used
Floating support for long shafts that expand with heat: drying cylinders of paper machines, fans, conveyor pulleys, rolls, drives with a long distance between supports. The outer ring can still have a tight fit in the housing.
When not to use
It takes no axial load, so it cannot be a locating support and does not replace a spherical roller bearing. The shaft must have a second support that locates it axially.
Technical data is for information only. Drawings may not show all design features.
