Cylindrical roller thrust bearing 81132 TN SKF 160 × 200 × 31 mm
Specifications
81132 TN SKF
- Designation
- 81132 TN
- Manufacturer
- SKF
- Inner diameter d
- 160 mm
- Outer diameter D
- 200 mm
- Height T
- 31 mm
- Dynamic load rating C
- 216 kN
- Static load rating C0
- 1 020 kN
- Limiting speed
- 1 700 rpm
- Nominal speed
- 850 rpm
- Weight
- 2.1 kg
- Chamfer radius r
- 1 mm
- Rolling elements
- Cylindrical roller bearings
- Load type
- Axial
Product summary
81132 TN: cylindrical roller thrust bearing, brand SKF. Bore diameter d 160 mm, outside diameter D 200 mm, mounting height T 31 mm. Dynamic load rating C 216 kN, static load rating C0 1020 kN, limiting speed 1700 rpm, weight 2.1 kg.
Line contact between cylindrical rollers and the washers: high axial load capacity at a low height.
Where it is used
Low-speed assemblies with high axial force: screw presses, jacks, extruders and injection moulding machines, vertical mills, drilling rig swivels, crane hooks.
When not to use
It takes no radial load and does not tolerate tilting of the washers: lack of parallelism causes edge contact and spalling of the roller ends, so it does not replace a spherical roller thrust bearing. In a fast assembly it does not replace a thrust ball bearing: there is sliding along the roller length, so heat generation increases.
Technical data is for information only. Drawings may not show all design features.
About the technical data
* - Technical specifications and other information are provided for reference only. We provide this data and believe the information to be reliable, however, no guarantee of accuracy or completeness of such information can be provided.
- Drawings and images may not reflect all design features of the product.
